OFFICE 52 at Carnegie Mellon

Form and Dichroic Light Scott Hall at Carnegie Mellon University Michelle LaFoe and Isaac Campbell OFFICE 52 Architecture Forward by Cesar Pelli, FAIA Introduction by Michael J. Crosbie, FAIA Leete”s Island Books, Maine USA Hard cover; 96 pages in color ISBN 9780918172709





In his introduction to Form and Dichroic LIght, Michael

Read more…

Expansion Strategies for a Challenging Campus Site

by Stanley Collyer

OFFICE 52 Higher Education Presentation 2015.05.13.indd
Winning proposal by Office 52 (courtesy ©Office 52)

Already ranked as one of the top engineering programs in the U.S., Pittsburgh’s Carnegie Mellon University (CMU) is hardly resting on its laurels. Scott Hall, anew Nano‐Bio‐Energy Technologies building scheduled for completion in early 2016, will undoubtedly enhance the University’s standing as a cutting edge research institution. Contrary to most curricula in the field of engineering, Nanotechnology is not based on a narrowly defined area of study; rather it is interdisciplinary in nature and can span the sciences and even reach into the arts. As a landlocked campus, a major challenge facing Carnegie Mellon is finding space for the construction of new facilities. The site chosen for Scott Hall in 2011 was at the western edge of the historic campus property, perched at the top of a neighboring ravine, Junction Hollow, and barely separated from three adjacent buildings. Although the campus master plan had already pinpointed a location for the new building, the University conducted a design competition to explore alternative solutions to a challenging site and a demanding interdisciplinary program.

Read more…

Addressing Affordable Housing in Bentonville

Login to see more (login problems? E: scollyer@competitions.org or http://competitions.org/contact/)

Adelaide Contemporary Art Museum Winner Announced

Login to see more (login problems? E: scollyer@competitions.org or http://competitions.org/contact/)

Adelaide Contemporary Art Museum Submissions Revealed



The designs of the six shortlisted teams that entered the Adelaide Contemporary competition are now on display.



Adjaye Associates and BVN with McGregor Coxall, Steensen Varming, Plan A Consultants, Barbara Flynn, Yvonne Koolmatrie, Aurecon Group and Front Inc





BIG – Bjarke Ingels Group and JPE Design Studio with United

Read more…

News from COMPETITIONS 12/20/2017

Login to see more (login problems? E: scollyer@competitions.org or http://competitions.org/contact/)

Munich Concert Hall Competition



1st Prize project by Cukrowicz Nachbaur Architekten (image © Cukrowicz Nachbaur Architekten)



Until the early 1970s, architecture in Bavaria, and in Munich in particular, was not only viewed as traditional, but even leaving the impression to some as being ‘quaint.’ Then came the 1972 Olympic Games, which marked a watershed moment in

Read more…

Review: A Rift in the Earth

Login to see more (login problems? E: scollyer@competitions.org or http://competitions.org/contact/)

Interview: William Pedersen FAIA (Winter 1996/97)




333 Wacker Drive – view with Chicago River in foreground (photo: ©Barbara Karant)



COMPETITIONS: When you are called on to design a ‘foreground’ building for a corporate client—although it’s usually an office building, it could be any number of building types—how do you balance the private and public interest beyond the usual zoning regulations?





























left and below
Gargoyle Club Prize
Best Architectural Thesis, University of Minnesota School of Architecture (1961)
Theme: Hospital Project


Images: courtesy William Pedersen



Pedersen: The interest of the client as it relates to the quantity of the construction they wish to place on a site is perhaps the most difficult issue, particularly during the 80s, when a tremendous amount of construction was taking place in the United States, and one more office building was not hailed by anybody as a contribution to society. The situation has changed rather dramatically in the 90s, when almost none of them are being built; so the issue is not as pressing. But there always is the question, ‘Is a building, given the bulk proposed, appropriate for its specific condition?’ One’s ability to deal with that issue is somewhat limited because zoning establishes what is of right, and not of right. Therefore, the battle has largely been fought prior to our entrance on the scene.



Past that point, the relationship of our buildings to a specific context has been a fundamental issue of our architecture. This is particularly how we take tall buildings, which are in themselves somewhat insular, autonomous and discrete, and bring them into a more social state of existence. That’s been the subject of our study for the last twenty years. We’ve developed strategies for doing that, of which I’ve spoken at length. The preoccupation of making the tall buildings—part of a more continuous, overriding fabric—that’s been central to our architecture.



COMPETITIONS: The most obvious argument against contextualism—as many people understand it—would be the Pompidou Centre in Paris, which has turned out to be the most visitied and popular building in that city. Wouldn’t that seem to give architects a good argument for doing something different? Was that even a lesson?



WP: Juxtaposition is a fundamental contextual strategy; but it has to be used sparingly and has to be introduced at exactly the right moment for it to have a powerful effect. For example, the Seagrams Building on Park Avenue—before any of the other buildings followed suit—was exceedingly powerful and very successful as a result of the juxtaposition at that particular place. I would argue that our building in Chicago (333 Wacker Drive) is an equally successful contextual building. It’s on the only triangular site of the Chicago grid at a bend in the Chicago River, and it sits within a context of totally masonry buildings, largely of the classical derivation. Somehow the relationship between those very distinct parts works. We were asked to build a building right next to 333 Wacker Drive, which did not occupy a unique geometric piece of property, but in fact became more of a continuation of the street wall leading up to 333 Wacker. We elected there to utilize a more Classical language in total juxtaposition to our own 333 Wacker in an effort to try to achieve the continuity of the wall that we thought was necessary, but also to maintain that poignancy of a juxtaposition to 333 Wacker Drive to the rest of the context. It would weaken it tremendously if it had been reproduced next door.



The same is true of the Pompidou Centre. If one were to tear down that section of Paris around it and build a number of Pompidou Centers there, it would lose its impact, because ifs impact is an object set within a very careful framing in that traditional neighborhood. Without the dialogue between the two, the game is over.




AAL Hqs. building addition (1971), Appleton, Wisconsin


AAL Hqs. original building


AAL rendering



COMPETITIONS: Most people seem to believe that 333 Wacker is the best building you have done. Maybe it was the time and unique site. It was one of those projects where one announces, ‘Well, here I am.’ Sometimes it’s difficult to top a wonderful building like that, though you may believe your next building is the one you like best.



WP: I think that 333 was a product of my sensibility at that point in time. It was a building that tended tobe an intuitive response to the site. In terms of it language, it came out of a couple of other buildings I had done immediately prior to that—one being the Aid Association for Lutherans in Appleton, Wisconsin, the other being the Brooklyn Criminal Courts Building, which had very similar geometric ideas in terms of its relationship to context. The very conscious attitude of trying to make the tall building part of a larger urban contet preoccupied us for the next five years. As a result, we used a more classical language to try to develop connecting strategies, because a Classical language is largely built on ideas of connection of pieces and parts, one to another…buildings connect well because they have parts that are combined and are part of a central language.



Read more…

The Vietnam Veterans Memorial Design Competition by Paul Spreiregen

This essay was published in The Architectural Competition – Research Inquiries and Experiences, Magnus Rönn, Reza Kazemian, Jonas E. Andersson (Eds.) Axl Books Stockholm, 2010 (pp. 578-600)

Introduction

The Vietnam War, 1959-75, was the longest and most divisive in American experience. 58,000 American soldiers died, 140,000 were wounded. Vietnamese casualties were far higher. The war caused permanent transformations in American society and culture. In 1979 Jan Scruggs, a Vietnam veteran, conceived the idea of a memorial to the memory of the American dead and, by implication, the veterans who had served. His further hope was that the memorial would reconcile the war’s veterans with the many Americans who had opposed the war. The memorial was to be sited in a place of honor on the Mall in Washington DC. It was to be privately funded as a citizen initiative, the federal government contributing the site. To undertake this effort a sponsor organization was created, the Vietnam Veterans Memorial Fund (VVMF), its board members including West Point and Naval Academy graduates. Legislation to authorize a memorial, guided by Senators Charles McC. Mathias Jr. and John W. Warner, was passed by the U.S. Congress in May 1980 and signed into law by President Jimmy Carter in July. All public design projects in Washington are subject to intensive scrutiny, especially memorials. Three federal agencies, responsible for approving the design in all its aspects, were closely involved throughout the effort. Discussions concerning a design competition for the memorial had begun in May. Competition planning began in July. The formal competition process was concluded ten months later, in May 1981. The 1,432 designs submitted in the competition, a then record number, were judged by an eight-person jury, all professionals representing the principal design disciplines. The competition was won by a 21-year-old student at Yale University, Maya Ying Lin. The memorial was built and dedicated in November 1982, with a statue group and flagpole addition dedicated in November 1984, the latter the result of sometimes bitter controversy regarding the basic Lin design. The memorial became and remains one of the most visited in the U.S., having become a virtual icon. Much has been written about the design and the designer, and much attention was given to the controversy. Little has been written about the competition process itself, a process based on the highest standards for conducting design competitions. This paper focuses on that process, its context and its conduct.


Personal Perspective

My experience with competitions began in architectural school, where they are integral to the architectural design studio. Following school, studying and working in Italy and Sweden, 1954-56, my interest grew. In Italy

I also became interested in contemporary memorials due to two examples related to WW II, both the products of competitions – the Ardeatine Caves near Rome and the Monument to the Deported in Milan. In Scandinavia that interest was broadened through studying the work of Gunnar Asplund, Sven Markelius, Alvar Aalto, and Arne Jacobsen – much of their work also the product of design competitions.

In 1955, on a visit to Sweden, I saw an exhibit of the competition entries for a proposed government center for Gothenburg. The winning entry was the work of Alvar Aalto. I was impressed by the simplicity and directness of Aalto’s drawings. His design, in my view among his most brilliant, was code named “Curia” in reference to a building in the Roman Forum. His submission was drawn in pencil on ordinary tracing paper. It included perhaps two or three constructed perspectives and photos of a massing model. The rest of his presentation consisted of plans, elevations and sections. Although this project was never realized the memory of the exhibit and the directness of Aalto’s drawings served as a guide in competitions that I later managed.

This general interest developed into the gradual realization that frequent and well-managed design competitions are a vital source for advancing creative design ideas. They are its exploratory test grounds. As important, they heighten the public’s interest and elevate public expectations of design, thereby establishing a vital environment for nurturing architectural creativity.

From 1966-70 I served as the first Director of Architecture and Design Programs at the then newly established National Endowment for the Arts, an opportunity that I used to try to promote their improvement and wider use in the U.S. In doing so I undertook an extensive study of competitions, historical and recent. I solicited the experience of architects from the US and abroad regarding their competition experience. I obtained and analyzed competition codes, mostly European and Scandinavian, but also the AIA code (destined to be withdrawn for legalistic reasons). Two products of my research were the book Design Competitions (McGraw Hill 1978) and, subsequently, the Handbook of Architectural Design Competitions (American Institute of Architects, 1981).

Unlike most European and Scandinavian countries, where the conduct of design competitions has been carefully regulated, in the US it has not. Although the federal government has had a limited program for certain “high profile” public buildings in recent years, in 1980 neither by the federal government, the constituent states, nor, least of all the AIA, the professional design organization of American architects, had any established and mandatory procedure for conducting design competitions. That condition has not basically changed. Conducting design competitions in the U.S. remains voluntary, entirely dependent on the sensibilities and skills of a project sponsor and the people enlisted to assist in it.

A sponsor of the requisite sensibilities proved to be the VVMF, who contacted the AIA for professional help. Since I was chairing the AIA’s committee on competitions at the time, developing the AIA Handbook, I was recommended to the VVMF as professional adviser. My first discussions with them were in May 1980. My work began in July, the same

month that full authorization for the Vietnam Veterans Memorial was procured. I worked directly with the VVMF Board and staff, but most closely with Robert Doubek, a West Point graduate and attorney.

Memorials and Competitions in Washington

Washington’s monumental character is the product of its 1791 baroque city plan and its largely neoclassic public buildings. That style also originates from the late 18th century. The earliest public buildings and monuments were products of design competitions — the U.S. Capitol, the White House, and the Washington Monument. Architect and later President Thomas Jefferson submitted seminal designs for the first two. Later works produced by design competitions include the Library of Congress, the Lincoln Memorial, and the Pan American Union. Inspired by Washington’s example, many of our individual states and municipalities utilized design competitions for their public buildings. One would think, then, that design competitions would be the norm for Washington, but that has not been the case.

In Washington, unfortunately, the practice became problematical. In the 1930s a design competition for a new Smithsonian museum, the winning design authored by Eliel Saarinen, had failed. The original effort to create a memorial to President Franklin D Roosevelt (FDR) through a design competition in the late 1950s had also failed. Other then recent memorials in Washington included the WW II Iwo Jima Memorial, a memorial to Senator Robert Taft, and the John F Kennedy Memorial. None were the result of design competitions. Beyond Washington there had been several recent and successful contemporary American memorial efforts, procured through open design competition, much esteemed by the general public. One was the Battleship Arizona Memorial in Pearl

The Gateway Arch, St Louis.

Gateway Arch competition drawing.

Battleship Arizona Memorial, Pearl Harbor, Hawaii.

FDR Memorial design, Washington DC.

Harbor, designed through a competition won by a WW II Austrian refugee, Alfred Preis. One of the finest of all American twentieth century memorials is the Gateway Arch in St Louis (the Jefferson National Expansion Memorial), designed by Eero Saarinen. It was the product of a very well conducted design competition held in the late 1940s.

Apart from the inherent difficulty of creating memorials in Washington, competitions aside, an equally grave reality was that after 1975 the American public was trying to put the Vietnam War in the past, in effect to forget it. The veterans and their families could not. Thus, while the idea of a memorial to our Vietnam Veterans was most deserving, considering both the difficulty of making memorials in Washington and the critical factor of public support, there was little reason for optimism on our part.

Federal Design Approval Agencies

Three century-old Federal agencies are responsible for the approval for the design of public architecture in Washington. To create a memorial in Washington it is essential to coordinate carefully with them. The agencies are: the National Park Service (NPS), which manages public park lands and virtually all of Washington’s memorials; the National Capital Planning Commission (NCPC), which approves land use and design; and the Commission of Fine Arts (CFA), which approves design. I had worked with all three. Their staffs were colleagues and friends. I knew their roles and responsibilities. Without compromising our work these agencies were involved on a working basis, mainly informational, from the inception of our effort.

Source of the Design Competition Methodology

A popular characterization of the predominant public architecture of Washington, most of it of classically inspired, is to refer to it as “beaux arts style”. In France, where the Institute of Fine Arts was founded centuries ago (l’Academie des Beaux Arts), and which included a school of architecture (l’Ecole d’Architecture) the term “beaux arts style” has no meaning. They would refer to Greek or Roman neoclassic precedents. Jefferson had introduced the idea of classical architecture to the U.S., inspired by his travels in France. From the 1870s until the depression of the 1930s many of America’s leading architects had studied at the Ecole. Because of the Ecole’s emphasis on neoclassicism and because so much American public architecture was neoclassic, the term “beaux arts” became an identifying style, a “brand”. This unfortunate misuse of the term obscures more significant aspects of the Ecole and its teaching methods.

The Ecole is remembered for its extraordinary students drawings. Normally expressed with great graphic virtuosity the drawings were, foremost, exercises in developing a student’s design knowledge and facility, utilizing the most refined design palette of the western world. But Greek and Roman classicism were by no means all that they explored. Students also made detailed construction drawings. And they made designs for sites and climates far from the Mediterranean, even as far as Alaska, and so as different in architectural expression as the climates. Such exercises were far from neoclassic in motif. The Ecole was much more than a copybook of styles.

The Ecole was a school for learning how to design real and complex buildings. In the course of the nineteenth century France evolved into a Republic, and the Ecole’s students

explored the possibilities for many novel types of buildings – schools, hospitals, and courthouses were typical subjects. Representative example designs accommodated many complex functions into a coherent workable form. The designs were depicted in plan, elevation, and cross section. Rarely did the students do perspective drawings. Their drawings, consisting of the three-part plan-section-elevation depiction system, had to be analyzed by the viewer for all their implications – appearance, function, structure, circulation, construction feasibility, spatial experience and hierarchy, visual emphasis, light, ventilation, etc. The artistic virtuosity demonstrated in the drawings can obscure the underlying purpose of architectural depiction in plan-section-elevation. Unlike perspective renderings, whose purpose is largely to allure, the purpose of depiction in plan-section-elevation is to inform. In order to be understood such drawings must be examined analytically, like a physician analyzing an x-ray. Thus the concomitant to this method of depiction is that it requires expert and experienced eyes to evaluate. It requires jurors of long experience and extensive expertise. In a large array of designs, as in a competition, the normal condition in the Ecole, jurors had to be capable of evaluating a design rapidly, to see the essence of an idea at a glance. Plan-section-elevation depiction also puts all design submissions, as in a competition, on an equal basis of comparison, one design with another. Thus, the cornerstone of an effective design exercise and its proper evaluation, certainly for a competition, was and remains clear and fully informative depiction on the one hand and evaluation by expert jurors on the other.

The Ecole’s depiction method was disseminated world-wide, wherever competitions were held, and it persisted after the demise of the Ecole in the 1960s. It continues today. It has persisted because it is a very good idea. Not surprising, then, are Eero Saarinen’s original very good idea.

Not surprising, then, are Eero Saarinen’s original competition drawings for the St Louis Gateway arch —plan-section-elevation—the same technique used in the Ecole.

Construction drawing, L’Ecole d’Architecture.

Project in Alaska, l’Ecole d’Architecture.

Looking southward into the memorial site.

Looking eastward from the memorial site to the Washington Monument.

True, Saarinen included a widely published perspective, but that was an accompaniment. The St Louis compe-tition brief required the traditional and proven depiction triad.

The Memorial Site

The site for the Vietnam Veterans Memorial, chosen with the guidance of NPS, was a small and quite inconsequential western corner of Washington’s central Mall, its monumental core. The selection of this site had been made by July 1980 when I was engaged as professional adviser. I concurred fully with the choice, feeling that if it were not possible to make a suitable memorial there it would not be possible to make one anywhere.

The site was a two-acre (0.8 hectare) area, a rough circle in form, 1000 feet (300 m) northeast of the Lincoln Memorial. To its east was an artificial pond called Constitution Gardens. To its south stood a row of neoclassic buildings of modest scale. The site itself was a quiet tree-lined meadow. Its special character, however, derived less from its interior, even less from what one saw looking into it, as what one saw looking out of it — looking from it. From the site one could see, principally, a striking view of the 555 foot high (169 m) Washington Monument 0.7 miles (1,120 m) to the east. To the southwest was a view of the Lincoln Memorial. The Washington Monument vista, unobstructed by trees, was clear throughout the year. The Lincoln Memorial vista is fully clear only in winter, when it is not obscured. Lesser vistas were of the US Capitol dome and several Smithsonian Institute landmarks buildings on the Mall. But the Washington Monument and the Lincoln Memorial were the main vistas, giving the site its special value.

Competition Planning and Execution
